1 RAPID CONFIGURATION
STEP 1 – CONNECT THE SYSTEM
25-Pin Models
To connect the system in a Stand Alone configuration, you need the hardware indicated in
Figure 1. In this layout the data is transmitted to the Host on the main serial interface. Data
can also be transmitted on the RS232 auxiliary interface independently from the main
interface selection.
When One Shot or Phase Mode Operating mode is used, the reader is activated by an
External Trigger (photoelectric sensor) when the object enters its reading zone.
Figure 1 – Matrix 210™ in Stand Alone Layout
