Datalogic P2x-Series User Manual

INTRODUCTION
2 P2X-SERIES™
P2x-Series™ (36 LEDs ILLUMINATOR)
Heatsink
The heatsink is mounted on the backside of the camera case.
1 Button (Camera Reset - Loader) 8 Internal Illuminator
2 Lens Cover 9 Bracket Mounting Holes (4)
3 Lens 10 Gigabit Ethernet Connection LED
4 Focus Adjustment Screw (on side) 11 Gigabit Ethernet Connector
5 Red Spot 12 Power - Serial Interfaces - I/O Connector
6 Green Spot 13 Power On LED
7 Lens Cover Screws 14 Illuminator screws
NOTE
The 36 LEDs illuminator can be mounted horizontally and vertically.
Connector block
rotates to 90° position
99
14
13
10
11
12
1
2
7
6
4
3
5
8
