GENERAL VIEW
PRODUCT REFERENCE GUIDE
3
Product Description
The P2x-Series™ cameras are Datalogic industrial compact 2D cameras produced to be a
high performance affordable solution for all machine vision applications.
The P2x-Series™ cameras are designed to be flexibly assembled for all machine vision
applications. Users can choose between:
• two different resolutions (qHD or 2MP)
• monochrome or color cameras
Cameras are licensed to connect to VPM. The Basic level is included on all the cameras.
The camera is contained in an aluminum housing. Mechanical dimensions are:
• 14LEDs illuminator
109 x 54 x 56 mm and it weighs about 380 g including the internal illuminator, lens and
protective cover
• 36LEDs illuminator
116 x 126 x 70 mm and it weighs about 640 g, including the internal illuminator, lens
and protective cover.
Electrical connection of Power and I/O signals is provided through an M12 (IP67) 17-pin
connector. A standard M12 (IP67) Gigabit Ethernet connector is also present.
Rugged construction, IP67 and IP65 protection and max 50°C operative temperature
make the P2x-Series™ the ideal product for industrial environments where protection
against harsh external conditions is required.
• Compact Industrial Smart Camera Series
• Right-angle IP67 and IP65 rated enclosure with rotating, sealed connectors
• Embedded interchangeable lenses and illuminators
• Built-in digital I/Os, Serial, and Gigabit Ethernet interfaces
• A variety of powerful Internal Lighting Systems
• Frame Rate up to 60 frames/sec (sensor)
• Supply voltage 24 Vdc ± 10%
Applications include:
Automotive
•Component verification
• Part Gauging
•Robot Guidance
• Laser Guidance
• Automotive Part Color
• Assembly Traceability
Electronics
•Measurements
• Positioning/Guidance
• Plating (Color)
• Assembly Traceability
CAUTION
Do not remove the heatsink from the camera body to avoid overheating.
