STEP 3 – MOUNT AND POSITION THE CAMERA
Use the P2x-Series™ mounting brackets to obtain the most suitable position for the
camera. The most common mounting configurations are shown in the figures below.
14 LEDs Illuminator
Figure 4- 14 LEDs Illuminator with STD Fix Bracket
36 LEDs Illuminator
Position 1
Figure 5 - 36 LEDs Illuminator with STD Fix Bracket
Pitch
Tilt
NOTE
This mounting position is valid also for Configuration A - External Lighting.
See "
Configuration A - External Lighting" on page 8
Tilt
Pitch
