58 P2X-SERIES™
CHAPTER 8
TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
Supply Voltage 24 Vdc ± 10%
Consumption (including
accessory internal illumina-
tor)
14 LEDs Illuminator: 0.42 A, 10 W max.
36 LEDs Illuminator: 0.62 A, 15 W max.
Communication Interfaces
Gigabit Ethernet
1000 Mbit/s
(supports application protocols: TCP/IP, EtherNet/IP, Profinet IO, Modbus TCP)
RS232 2400 to 115200 bit/s
Inputs
Input 1 (External Trigger) and
Input 2
Opto-isolated and polarity insensitive
Max. Voltage 30 Vdc
Max. Input Current 10 mA
Outputs
a
Output 1 and 2
• NPN or PNP short circuit protected (configure in VPM-Camera Setup)
• Opto-isolated only when connected to CBX500/800
Output 3
• NPN or PNP short circuit protected (configure in VPM-Camera Setup)
• Opto-isolated only when connected to CBX800
• Strobe signal connection shared with Output 3. Output 3 is active
only
if the
External Strobe is disabled. (Configure in VPM- Impact)
V
OUT
(I
LOAD
= 0 mA) Max.
24Vdc
V
OUT
(I
LOAD
= 100 mA) Max.
3 Vdc
Load Max 100 mA
OPTICAL FEATURES
Image Sensor CMOS sensor with Global Shutter
Image Color, Monochrome
Pixel Size
2.0 Mpixel: 2.8 µm square
qHD: 5.6
µm square
Image Format
2.0 Mpixel: 1920x1080
qHD: 960 × 540
Imager Size
6.18 µm diagonal
1/2.8 inches
Max. Frame Rate (sensor) 60 frames/sec
Led Safety
according to EN 62471
