PREFACE
vi
P2X-SERIES™
Reseller Technical Support
An excellent source for technical assistance and information is an authorized Datalogic
reseller. A reseller is acquainted with specific types of businesses, application software,
and computer systems and can provide individualized assistance.
All necessary firmware is installed on the P2x-Series™ camera at the factory. Vision Pro-
gram Manager (VPM) software must be installed to configure the camera inputs, strobe,
general purpose outputs, and internal illuminators. Installation software can be down-
loaded from the Datalogic web site.
COMPLIANCE
Connect Gigabit Ethernet and dataport connections to a network which has routing only
within the plant or building and no routing outside the plant or building.
Power Supply
ATTENTION: READ THIS INFORMATION BEFORE INSTALLING THE PRODUCT
This unit is intended to be powered by an external power supply ES1, PS2 according to
IEC 62368-1:2014.
EMC Compliance
In order to meet the EMC requirements:
• connect reader chassis to the plant earth ground by means of a flat copper braid
shorter than 100 mm;
• for CBX connections, connect pin “Earth” to a good Earth Ground;
• for direct connections, connect your cable shield to the locking ring nut of the connec-
tor.
CE Compliance
CE marking states the compliance of the product with essential requirements listed in
the applicable European directive. Since the directives and applicable standards are sub-
ject to continuous updates, and since Datalogic promptly adopts these updates, there-
fore the EU declaration of conformity is a living document. The EU declaration of
conformity is available for competent authorities and customers through Datalogic com-
mercial reference contacts. Since April 20th, 2016 the main European directives applica-
ble to Datalogic products require inclusion of an adequate analysis and assessment of
the risk(s). This evaluation was carried out in relation to the applicable points of the
standards listed in the Declaration of Conformity. Datalogic S.r.l. products are mainly
designed for integration purposes into more complex systems. For this reason it is under
the responsibility of the system integrator to do a new risk assessment regarding the
final installation.
Warning
This is a Class A product. In a domestic environment this product may cause radio inter-
ference in which case the user may be required to take adequate measures.
NOTE
Throughout this manual, the name “VPM” is used to refer to the software
installed on the camera.
