INTRODUCTION
8
P2X-SERIES™
Necessary camera components
Configuration A - External Lighting
Configuration B1 - 14 LEDs Illuminator
6 MM 8 MM 12.5 MM 17.5 MM
Narrow
Angle
Lighting
LTP 110-350 SN14L 35D
RED 625nm
LTP 112-350 SN36L 35D
RED 625nm
LTP 110-351 SN14L 35D
WHT white
LTP 112-351 SN36L 35D
WHT white
LTP 110-352 SN14L 35D
BLU 475nm
LTP 112-352 SN36L 35D
BLU 475nm
Body
Spacer
Lens
Cover
+++
+++
Body
LTP 14 LED
Lens
Cover
