3.10 Dummy Module
3.10.1 Profiles and Dimensions
 Dummy module AHASP01-5A
1
2
3
4
Number
Name
Description
1 Label Nameplate
2
Set screw
Fixing the module
3
Connector
Connecting the module and a backplane
4 Projection Fixing the module
Dimensions:
110
35
6
103
Dimensions are in mm.
