Delta AH Motion Series User Manual

Chapter 4 Installation and Wiring
4-7
4_
4.2 Points to Note on Installation
 An AH Motion system only supports the horizontal installation, and a power supply module has to be installed on the
left-most side of a backplane.
 Product dimensions (modules, backplanes, cables and more) should be confirmed when making an installation layout.
To obtain sufficient installation space, you should also save proper wiring space for connectors, cables and other
instruments.
 Make sure that the work environment conforms to the specifications for the products. It is necessary to take account of
the basic temperature/humidity control and the dust/corrosion prevention.
 The electromagnetic interference will result in the wrong action of the whole system. Therefore, you have to do EMC
design carefully. Refer to Appendices in this manual for more information related to EMC standards.
 If the specifications for the components such as screws and washers are noted specifically in the manual, use the
components conforming to the specifications.
 If a cable is connected to a communication port, make sure that the connector of the cable is joined to the port on the
module properly.
 A backplane has to be mounted on a plane stably instead of being just set on the plane. After it is installed, make sure
that it is fixed on the plane.
4.3 Installation
4.3.1 CPU Rack Installation in a Control Panel
The motion controller has to be installed in a closed control box. In order to ensure that the PLC disapates heat properly,
the space between the motion controller and the control box has to be larger than 50 millimeters.
50mm＞
50mm＞
50mm＞
50mm＞
10EMC
06XA
10SCM
10DNET
10COPM
16AN01T
 Keep the motion controller away from high-voltage equipment, high-voltage wires, and high-voltage motors.
 In order to prevent the temperature of a motion controller from rising, do not install the motion controller vertically on
the bottom/top in the control box.
 Install a motion controller horizontally in the control box, as shown above.
 If you intend to increase the number of modules, you have to leave some space for installing the modules in the control
box.
4.3.2 Mounting a Backplane
 Fixing a backplane by screws
