Delta AH Motion Series User Manual

AH Motion – Hardware Manual
4-64
_4
4.8 Wiring Digital Input/Output Modules
The wiring of digital input/output modules is illustrated simply in this section. The simplistic wiring diagrams below also
illustrate how the power supplies are connected to S/S, UP, ZP and COM. If you want to get more information about the
wiring of digital input/output terminals, you can refer to section 4.9 in this manual.
4.8.1 Wiring AH16AM10N-5A
Input form
Direct current (sinking or sourcing)
Input current
24 VDC, 5 mA
7
10
12
11
9
8
6
5
4
3
2
15
14
6
7
13
S/S
24VDC 5mA
1
0
16AM10N
0 2 31
5
4
S/S
98 1510 11 12 13 14
