4.8.7 Wiring AH16AP11R-5A
Input form
Direct current (sinking or sourcing)
Input current
24 VDC, 5 mA
Output type
Relay-R
Voltage specifications
24 VDC, 240 VAC, 2 A
COM1
1
0
10 3 42
7
6
5
L
0
L
L
2
1
S/S
6
5
4
3
2
7
3
5
L
L
L
6
7
COM0
L
L
4
24VDC 5mA
240VAC 2A
16AP11R
10 432
7
6
5
