FAULT FINDING AND REPAIR
20509 Issue 7 Jan 2018 4-7
(4) Pressure too low (see page 4-21, steps (7) and (8)) or intensity too low.
(5) Pressure too high (see page 4-21, steps (7) and (8))
(6) Incorrect solenoid adjustment - note varying drop sizes (see page 3-
9).
(7) Air in print head - note drops not properly formed (see page 4-8).
(8) Splashing on substrate - pressure too high (see page 4-21, steps (7)
and (8)).
