Maintenance Manual (960-945)
4-39
Replacement Procedures
Figure 4-42 Installing the LCD unit (2)
6.
Remove the separat
ors on th
e bottom si
de of the LCD mask.
7.
Align the LCD mask to the botto
m side of the LC
D
cover first
and
engage the latches.
When
replacing the
LCD mask
w
ith
a
new one,
S
tick
the
CAMERA
P
ANEL
on the LCD mask in place and re
move th
e separator on it.
CAMERA
P
ANEL
114
116
