TRSM0940 Service Procedures | Shift Bar Housing Disassembly and Assembly
Shift Bar Housing Disassembly and Assembly
Special Instructions
None
Special Tools
None
Component Identification
*Due to design changes please verify the part number on the component to ensure proper part replacement.
1. Detent Cap Assembly
2. Ball and Spring
3. Reverse Plunger (?)
4. Shift Bar Housing
5. Cap Screws (x16)
6. Actuator Assembly (?)
7. Neutral Switch Interlock (?)
8. Air Valve Shaft
9. Reverse / LO Shift Yoke*
10. Lock Screws
11. Reverse / LO Shift Rail
12. Direct / Overdrive Shift Yoke
13. 1st / 2nd Shift Yoke
14. 1st / 2nd Shift Rail
15. Steel Balls (x2)
16. 1st / 2nd Shift Block (?)
17. Direct / Overdrive Shift Block (?)
18. Shift Block
19. Shift Rail
1
2
4
5
8
9
11
14
15
18
19
13
10
10
10
10
10
12
