Main Shaft Speed Sensor Removal and Installation | Service Procedures TRSM0940
Main Shaft Speed Sensor Removal
1. Disconnect the Transmission Harness from the Main
Shaft Speed Sensor pigtail.
2. Using a
3/8” socket, remove the bolt from the retaining
clip.
3. Th
e clip will not remove from the speed sensor.
Remove the Main Shaft Speed Sensor, with O-ring,
from the rear of the Shift Bar Housing.
