TRSM0940 Service Procedures | Gear Position Sensor Removal and Installation
Gear Position Sensor Removal
1. Disconnect the Transmission Harness from the Gear
Position Sensor.
2. Using
a 5/32” hex key wrench, remove the two (2) sen-
sor hex key mounting screws.
Caution: Carefully allow sensor to rotate to
a relaxed
position, or sensor can snap when the hex key mount-
ing screws are removed.
3. Remove the
Gear Position Sensor and gasket from the
housing.
!
