Transmission Harness Removal and Installation | Service Procedures TRSM0940
Transmission Harness Removal and Installation
Special Instructions
None
Special Tools
Basic hand tools
Component Identification
1. 38-way Transmission Electronic Control Unit (TECU) Connector
2. Gear Sensor Connector
3. Rail Sensor Connector
4. 4-way Diagnostic Connector
5. Input Shaft Speed Sensor Connector
6. 8-way Electronic Clutch Actuator (ECA) Connector
7. Range Solenoid Connector
8. Output Shaft Speed Sensor Connector
9. Engine Speed Sensor Connector
10. Main Shaft Speed Sensor
11. X-Y Shifter Connector
12. Terminating Resistor Connector
7
8
11
11
1
3
2
5
9
12
6
4
10
