The display shows the configured display variables. For each display variable, the display
reports the abbreviated name of the process variable (for example, DENS for density), the
current value of that process variable, and the associated unit of measure (for example, G/
CM3).
If Auto Scroll is enabled, the display cycles through the display variables, showing each
display variable for a user-specified number of seconds. Whether or not Auto Scroll is
enabled, you can activate Select to move to the next display variable.
Transmitter display featuresFigure 8-1:
A. Display (LCD panel)
B. Process variable
C. Scroll optical switch
D. Optical switch indicator: turns red when Scroll is activated
E. Optical switch indicator: turns red when Select is activated
F. Select optical switch
G. Unit of measure for process variable
H. Status LED
I. Current value of process variable
8.2.2 View process variables and other data using ProLink III
Monitor process variables, diagnostic variables, and other data to maintain process quality.
ProLink III automatically displays process variables, diagnostic variables, and other data on
the main screen.
Tip
ProLink III allows you to choose the process variables that appear on the main screen. You can also
choose whether to view data in Analog Gauge view or digital view, and you can customize the gauge
settings. For more information, see the ProLink III user manual.
8.2.3 View process variables using the Field Communicator
Monitor process variables to maintain process quality.
Transmitter operation
106 Micro Motion
®
Fork Density Meters (FDM)
