Related information
Sample calibration certificate
4.1.1 Calibration factors
The original calibration factors are obtained from factory calibration, and are unique to
each device. They are used to adjust measurements for the specific physical properties of
the device.
The calibration certificate contains two sets of factors:
Density calibration
coefficients
Define the relationship between density and the response
of your sensor
Temperature
compensation coefficients
Adjust density measurement for the effect of temperature
on sensor response
The calibration certificate also provides the results of the Known Density Verification
procedure that was performed at the factory.
For each calibration performed at the factory, the calibration certificate contains the data
used to calculate the calibration coefficients.
Related information
Sample calibration certificate
4.2 Configure line density measurement
The density measurement parameters control how density is measured and reported.
• Configure Density Measurement Unit (Section 4.2.1)
• Configure Density Damping (Section 4.2.2)
• Configure Density Cutoff (Section 4.2.3)
• Configure two‐phase flow parameters (Section 4.2.4)
4.2.1 Configure Density Measurement Unit
Display OFF-LINE MAINT > OFF-LINE CONFG > UNITS > DENS
ProLink III Device Tools > Configuration > Process Measurement > Line Density > Density Unit
Field Communicator Configure > Manual Setup > Measurements > Density > Density Unit
Overview
Density Measurement Unit controls the measurement units that will be used in density
calculations and reporting.
Configure process measurement
20 Micro Motion
®
Fork Density Meters (FDM)
