F
Remove the protective sheet that is on the
cleaning sheet.
The gray area indicated by A is adhesive face.
Do not touch it with your hands or anything else.
G
Insert the cleaning sheet until it reaches the end
of the roll paper feed slot, and then pull it out.
Repeat this two or three times.
To clean the roll paper feed slot from end to
end, do it several times on the right side, center,
and left side sections.
H
Press the Y button. If you want to stop a job as
is, press the P button on the printer to turn off
the power. If you want to continue, see the
following, according to the job to be done.
U “Loading Roll Paper” on page 31
U “Loading Cut Sheets” on page 38
Note:
If the cleaning sheet gets fed, press the Y button
and then remove the cleaning sheet.
You cannot reuse a cleaning sheet that has been used
once.
Cleaning Inside the Printer
A
Make sure the printer is turned off and the
screen has turned off, and then unplug the
power cable from the outlet.
B
Leave the printer for a minute.
C
Open the printer cover and use a soft, clean
cloth to carefully wipe away any dust or dirt
inside the printer.
Wipe the pink part shown in the following
illustration. To avoid spreading the dirt, wipe
from the inside to the outside. If there is a
serious dirt problem, clean it using a soft, clean
cloth dampened with a mild detergent. Then,
wipe the inside of the printer with a dry, soft
cloth.
c
Important:
❏ When cleaning, do not touch the roller
and the ink absorption parts (gray parts)
in the illustration above; otherwise,
prints may be soiled.
❏ Be careful not to touch the ink tubes
inside the printer, otherwise, the printer
may be damaged.
SC-P5000 Series User's Guide
Maintenance
139
