Take-up with the Printed Side
Facing Out
A
Cut the paper tape approximately 70 cm in
length, and paste it approximately in the center of
the media using commercially available adhesive
tape.
B
While pulling the paper tape straight down, wrap
it around the roll core from front to back, and
affix it using commercially available adhesive
tape.
c
Important:
Attach the media to the take up roll core with
the media in a taut state. If media is attached
in a loose state, the media may move around
during take-up.
C
Flip the Auto switch to .
D
Lower the tension bar until it slightly touches the
paper tape.
SC-S80600 Series/SC-S80600L Series/SC-S60600 Series/SC-S60600L Series/SC-S40600 Series User's Guide
Basic Operations
39
