C
Lower the roll onto the roll support.
D
To prevent the media from sliding off the roll,
support the roll at its right end.
E
Loosen the right roll core holder fixing screw and
remove the roll core holder from the roll.
F
Lower the roll onto the roll support.
G
To remove media from the rear media feeding
unit, reverse the steps you followed to load it.
Before Printing
To maintain print quality, perform the following
inspection before starting work each day.
Check the amount of ink remaining:
If ink is expended while printing, printing can be
resumed once the affected ink cartridge/ink supply unit
has been replaced. However, when replacing ink during
a print job, you may see a difference in color depending
on the drying conditions. If you know that the print job
will be a large one, we recommend that you use new ink
cartridges/ink supply units to replace those that are
running low before you start. The old ink cartridges/ink
supply units can be re-inserted and used at a later date.
Ink level is shown by an icon. U “Understanding the
Display” on page 16
Replacing Ink Cartridges U “Replacement procedure”
on page 72
Replacing Ink Supply Units U “Replacement
procedure” on page 75
Shaking WH/MS inks (when 10 color mode is selected
in SC-S80600 Series/SC-S80600L Series)
WH/MS inks may sediment easier than other inks due
to ink characteristics.
Before starting printing operations for the day, remove
the ink cartridges/ink supply units and thoroughly
shake them back and forth approximately 15 times in 5
seconds.
Shaking Ink Cartridges U “Shaking” on page 71
Shaking Ink Supply Units U “Shaking” on page 74
Print Check Pattern
Print a check pattern to check for clogged nozzles.
Perform head cleaning if parts of the pattern are faint or
missing.
Print a Check Pattern U “Printing nozzle check
patterns” on page 85
Head Cleaning U “Head Cleaning” on page 86
SC-S80600 Series/SC-S80600L Series/SC-S60600 Series/SC-S60600L Series/SC-S40600 Series User's Guide
Basic Operations
54
