198
External Dimensions
Main unit outline drawings
•Width: 392 mm {15.43"}
•Depth: 598 mm {23.54"}
Absolute maximum rated 70 C {158 F}
Pressure
(elevation)
Operating 700 to 1060 hPa (approximately 0 to 2,500 m above sea level)
{approximately 0 to 98425.20”}
Not operating
(including in
transportation)
700 to 1060 hPa (approximately 0 to 2,500 m above sea level)
{approximately 0 to 98425.20”}
Vibration
resistance
When packed Frequency: 5 to 55 Hz
Acceleration: Approximately 19.6 m/s2 {2 G}
Sweep: 10 minutes (half cycle)
Time: 1 hour
Orientation: x, y, and z
Shock
resistance
When packed Packing: Epson standard package specifications
Height: 45 cm {17.72"}
Orientation: 1 corner, 3 edges, and 6 surfaces
When unpacked Height: 5 cm {1.97"}
Orientation: Lift one edge and release it (for all 4 edges)
Noise During
operation
Approximately 55 dB (ANSI Bystander position)
Based on Epson evaluation conditions including the use of the
autocutter.
Item Specification
