7.4.3 Definition of Program 9 for Pulse-Steady-State Training
Program 9 offers pulse-steady-state training capability. A continuously available heart
rate input is prerequisite for this program. Heart rate input can be accomplished in
various ways. You can attach an ear/finger clip, a pulse monitor (such as the Polar
Pacer) or connect a QRS trigger output from an ECG device being used (see Annex E
to this operator’s manual).
" Call up program creation as described in the
preceding section.
" Select program 9 in the field „Program No“.
" Now you can set the individual parameters.
The significance of the parameters for this
special analysis program are described be-
low.
The cursor will automatically skip to the next
field when entry is complete for the current
field. Complete entry must be made in each
field in accordance with the number of char-
acter positions provided
(Example: Start Load Po = 3 characters; en-
try value of 50 watt would be entered as &P
0
= 050W).
The arrow keys may be used to move to any
field desired. The display will scroll automati-
cally when the upper or lower display margins
are reached.
" Close data entry with the „RETURN“ key.
Now program 9 is configured in accordance
with your choices. Any parameter may still be
changed at the beginning of ergometry for a
specific ergometric run.
$$
$$
$
ACTIVATE PROGRAM M
Program No 0 > X<
max. HEARTFREQ. HF < XXX
max. Syst. S < XXX mmHg
%
%
%
$$
$$
$
ACTIVATE PROGRAM M
max . Diast . D< XXX
START LOAD Po = XXX W
max . LOAD Pmax = XXX W
$$
$$
$
ACTIVATE PROGRAM M
Interv . BPM = XX min . 0
PWC = XXX PWC = XXX
TRAININGIND. [ Y / N ] N
$$
$$
$
ACTIVATE PROGRAM M
LOAD STEP 01 - 12 0
INTERV. LOAD = XX min .
LOAD CHANGE XXX W
$$
$$
$
%
%
%
Configuration
