4.14.8 Additional Vehicle Signals
/ Features
Reverse Signal
A reverse signal is available on the tail light
connector. In order to avoid electrical issues due
to leakage, and to ensure connector
compatibility, a mating connector with
seals/plugs and pre-crimped wire & terminal
should be used. For Additional information refer
to Adding Connectors, Terminals and Wiring in
this manual.
NOTE: It is not recommended that signal is used
to drive auxiliary equipment directly – a relay (max
300mA) should be used. The existing reverse
light load is close to the threshold and is
hard-wired through the Central Junction Box for
current sensing to generate the appropriate CAN
message.
Chassis Cab (for information only)
ColorWire CSAFunctionPin
Black-Yellow1.5Ground1
Violet-White1.5Brake Light2
Yellow-Green0.5Park Light3
Green-Orange0.75Direction Indicator4
Green-Brown0.75Reverse Light5
Red0.75Fog Light6
Van, Bus and Kombi (for information only)
ColorWire CSAFunctionPin
Green-Brown0.75Reverse Light1
Green-Orange0.75Direction Indicator2
Yellow-Green0.5Park Light3
Violet-White1.5Brake Light4
Black-Grey / Black-Green1.5Ground5
0.75Fog Light6
FordTransit 2006.5 (April 2006–)
Date of Publication: 12/2006
4 Electrical
147
