5.6 Glass, Frames and Mechanisms
5.6.1 Rear Windows
For windows, it is recommended to specify the
base vehicle as a Kombi or Bus body - however,
when converting a van, the following should be
adhered to:
•
Cut the outer panel of the body side and door
to within 1mm of the inner panel flange.
•
Do not cut across panel joints or pillars.
•
Use approved glass for installation according
to legal requirements.
WARNING: Do not install seats in the
cargo area of a Van. In case rear
seats are required, always specify
the base vehicle as Kombi or Bus.
DescriptionItem
Short Wheel BaseA
Medium Wheel BaseB
Long Wheel BaseC
Extra Long Wheel BaseD
FordTransit 2006.5 (April 2006–)
Date of Publication: 12/2006
5 Body and Paint
211
