Van and Kombi
Van and Kombi Driver and Passenger Weight Distribution
Weight distribution Per Person in
Kg
'D' Third
Row Seats
'C' Second
Row Seats
'B' Front
Row Seats
and Driver
'A' Wheel-
base (mm)
TotalOn Rear
Axle
On Front
Axle
752649--9852933
755124-1859--
757412916---
752352--9853300
754530-1859--
7549262916---
752055--9853750
754035-1859--
7525502916---
Dimensions taken from Front Axle (1)
1.16.2 Center of Gravity
The following charts show the Center of Gravity
used for Brake Certification at Kerb and maximum
Gross Vehicle Mass also the beneficial effect of
fitting a High Center of Gravity pack.
FordTransit 2006.5 (April 2006–)
Date of Publication: 12/2006
1 General Information
46
