1.15 Hardware—Specifications
Material Specification, Strength and Torque
Standard Hardware and Tightening Torques (Nm) Bolts/Studs: ISO 898-1, Nuts:
ISO 898-2
Grade 10.9Grade 8.8Grade 4.8
MaximumMinimumMaximumMinimumMaximumMinimumThread Size
3.42.41.41.1M4
6.74.92.72.2M5
15.011.011.58.54.73.7M6
35.025.028.020.0M8
70.050.055.041.0M10
125.095.092.068.0M12
200150153113M14
310.0230.0230.0170.0M16
399.4317.5317.0252.0M18
541.8434.7430.0345.0M20
743.4592.2590.0470.0M22
945.0756.0750.0600.0M24
FordTransit 2006.5 (April 2006–)
