5.2 Body System - General Information—Specifications
5.2.1 Van Floor - Load Compartment Tie Downs for Van ,Bus and
Kombi
Plain M8 weld nuts are supplied as standard on
right hand drive vehicles and available to order
as an option on left hand drive vehicles.
Alternatively the floor can be drilled, with care, to
access the weld nuts. Use M8 thread rolling bolts.
The forward load compartment tie down is not
available in combination with the side load door(s).
For details see the following figures E74505,
E74506, E74507, 74508 and table 'Dimensions
to locate Compartment Tie Downs'.
Location of Underfloor M8 Weld Nuts for Short Wheel Base
FordTransit 2006.5 (April 2006–)
Date of Publication: 12/2006
5 Body and Paint
200
