Communication
Network Server addresses for data transfer
If a firewall is used for outgoing connections, the following protocols, server addresses
and ports must be allowed for successful data transfer:
- Tcp fronius-se-iot.azure-devices.net:8883
- Tcp fronius-se-iot-telemetry.azure-devices.net:8883
- Tcp fronius-se-iot-telemetry.azure-devices.net:443
- Udp sera-gen24.fronius.com:1194 (213.33.117.120:1194)
- Tcp froniusseiot.blob.core.windows.net:443
LAN:
1
Enter host name.
2
Select connection type “automatic” or “static”.
3
For connection type "static" - enter IP address, subnet mask, DNS and gateway.
4
Click on the "Connect" button.
The connection is established.
WLAN:
Establishing a connection via WPS:
1
Click the "Enable" button.
2
Activate WPS on the WLAN router (see documentation provided with the WLAN
router).
The connection is established automatically.
Select and connect WLAN network:
The networks found are shown in the list. Clicking on the refresh button will carry out a
second search of the available WLAN networks. The "Find network" input field is used to
find hidden networks.
1
Select network from the list.
2
Select connection type “automatic” or “static”.
3
For connection type "automatic" - enter WLAN password and host name.
4
For connection type "static" - enter IP address, subnet mask, DNS and gateway.
5
Click on the "Connect" button.
The connection is established.
102

Fronius Primo GEN24 3.0 Plus Specifications

General

Max. input current	12 A
Max. input voltage	1000 V
Protection class	IP66
Max. output current	13 A
THD	< 3%
Max. input current (DC)	12 A
Number of MPP trackers	2
Max. DC short-circuit current	18 A
AC Output Frequency	50/60 Hz
AC nominal output	3000 W
Max. apparent AC power	3000 VA
AC nominal voltage	230 V
Operating Temperature Range	-25 to +60 °C
Cooling	Active cooling
Maximum Input Power	4, 500 W
Warranty	5 years
