Fronius Primo GEN24 3.0 Plus User Manual

Grid
supplies the loads in the system if insufficient power is being generated
by the PV modules or supplied by the battery.
Operating mode –
Inverter with bat-
tery
In order to be able to obtain the highest rate of self-consumption with your PV system, a
battery can be used to store excess energy. The battery is coupled to the inverter on the
direct current side. Multiple current conversion is therefore not required, and the effi-
ciency is increased.
Operating mode –
Inverter with bat-
tery and several
Smart Meters
17
EN

Fronius Primo GEN24 3.0 Plus Specifications

General

Max. input current	12 A
Max. input voltage	1000 V
Protection class	IP66
Max. output current	13 A
THD	< 3%
Max. input current (DC)	12 A
Number of MPP trackers	2
Max. DC short-circuit current	18 A
AC Output Frequency	50/60 Hz
AC nominal output	3000 W
Max. apparent AC power	3000 VA
AC nominal voltage	230 V
Operating Temperature Range	-25 to +60 °C
Cooling	Active cooling
Maximum Input Power	4, 500 W
Warranty	5 years
