Replacing Consumables
71
Maintenance
3
• When the C3 Finisher Staple Unit 65 Sheets is
installed, pull down the orange lever, and pull
out the staple cartridge.
4 Pinch both sides of the empty staple case with
your fingers (1), and pull out the staple case
from the cartridge (2).
Important • The staple case cannot be removed when the
staples are remained in the staple case.
Forcibly removing the staple case may cause
machine malfunction.
5 Insert the front side of the new staple case into
the staple cartridge (1), and then push the rear
side into the cartridge (2).
6 With grasping the orange lever of the staple
cartridge, push the staple cartridge into its
original position until it clicks into place.
7 Close the finisher front door.
Note • If the front door is not closed completely, a message appears and the machine will remain paused.
Replacing Staple Cartridge
(for D2-Staple-Finisher or D2-Staple-Finisher with Booklet Maker)
When the D2-Staple-Finisher (optional) or D2-Staple-Finisher with Booklet Maker (optional)
is installed and the staple cartridge needs to be replaced, a message appears on the touch
screen. When this message appears, load a new staple case into the staple cartridge.
This section explains how to replace the staple cartridge in the D2-Staple-Finisher with
Booklet Maker, as an example. You can apply the same procedures for the D2-Staple-
Finisher.
Important • The use of staple cartridges not recommended by Fuji Xerox may degrade quality and performance.
Use only staple cartridges recommended by Fuji Xerox.
1
2
