Replacing Consumables
75
Maintenance
3
7 Close the cover.
8 Return the booklet staple cartridge to its
original position.
9 Slightly push the booklet staple cartridge
upwards, and make sure that it clicks into place.
Note • Return the booklet staple cartridge until ( )
of the booklet staple cartridge is fitted in
( ) of the booklet unit.
10 Return the booklet unit to its original position.
11 Close the finisher front door.
Note • If the front door is not closed completely, a message appears and the machine will remain paused.
Replacing Booklet Staple Cartridge
(for D2-Staple-Finisher with Booklet Maker)
When the D2-Staple-Finisher with Booklet Maker (optional) is installed and the booklet
staple cartridge needs to be replaced, a message appears on the touch screen. When this
message appears, load a new staple case into the booklet staple cartridge.
Important • The use of staple cartridges not recommended by Fuji Xerox may degrade quality and performance.
Use only booklet staple cartridges recommended by Fuji Xerox.
• When the machine is in Energy Saver mode, exit Energy Saver mode by pressing the <Energy Server>
button and the <Machine Status> button on the control panel before you replace the booklet staple
cartridge.
• When you replace the booklet staple cartridge, press the <Machine Status> button and check the
current status for the booklet staple cartridge even when the control panel is lit.
Note • To order a booklet staple cartridge, contact our Customer Support Center.
