200 Troubleshooting
Entering Values
Using the Operator Panel
Using the operator panel, enter the values that you found in the color registration chart to make
adjustments.
1 Press the (Menu) button.
2 Select Admin Menu, and then press the button.
3 Select Maintenance Mode, and then press the button.
4 Select Adjust ColorRegi, and then press the button.
5 Select Enter Number, and then press the button.
6 Confirm that Enter (Y, M, C) appears, and then press the or button until you reach the
value (for example, +3) displayed on the chart.
7 Press the button once and move the cursor to the next color.
8 Repeat steps 6 and 7 to enter all of the digits, and then press the button.
9 Confirm that Enter (LY, LM, LC) appears.
10 Press the or button until you reach the value (for example, +3) displayed on the chart.
11 Press the button once and move the cursor to the next color.
12 Repeat steps 10 and 11 to enter all of the digits, and then press the button.
13 Confirm that Enter (RY, RM, RC) appears.
14 Press the or button until you reach the value (for example, +3) displayed on the chart.
15 Press the button once and move the cursor to the next color.
16 Repeat steps 14 and 15 to enter all of the digits, and then press the button.
The top screen appears.
17 Perform steps 1 to 4 to enter the Adjust ColorRegi menu.
18 Select Color Regi Chart, and then press the button.
The color registration chart is printed with the new values.
19 Adjust until all straight lines are at the value of 0. Viewing the images before and after will help.
