126 Upgrade and Maintenance Manual TX100 S3 Core Edition
Main memory
10.3.3 Removing a memory module
Ê Identify the desired memory slot according to the mounting order described
in section "Memory sequence" on page 120.
V CAUTION!
Ensure to maintain an operational configuration when removing
memory modules. For additional information, please refer to section
"Operation modes" on page 121.
Figure 69: Removing memory modules
Ê Eject the desired memory module by pressing out the securing clips at each
end of the memory module connector (1).
Ê Remove the ejected memory module (2).
10.3.4 Concluding steps
Perform the following procedures to complete the task:
Ê Close the side cover as described in section "Installing the side cover" on
page 56.
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 57.
Ê If available, update the system board BIOS to the latest version as described
in section "Updating the system board BIOS via USB stick" on page 67.
/
/
