190 Upgrade and Maintenance Manual TX100 S3 Core Edition
Front panel and external connectors
13.2.7 Installing the new front USB module
Figure 125: Installing the front USB module
Ê Mount the new front USB module as shown and secure it with four screws
(see circles).
