Fujitsu PRIMERGY TX100 S3 Core Edition Upgrade And Maintenance Manual

242 Upgrade and Maintenance Manual TX100 S3 Core Edition
Appendix
16.3.2 Connectors and indicators on the front panel
16.3.2.1 Front panel connectors and indicators
Figure 160: Front panel connectors and indicators
Pos. Component
1 On/Off button / Power-on indicator
2 HDD activity indicator
3 Front USB connectors (x2)
1
/
0
