xi
SYSTEM CONFIGURATION
Basic configuration is shown below with solid line.
Equipment category
Antenna Unit: Exposed to the weather
Other Equipment : Protected from the weather
GPS navigator
Satellite compass
Heading sensor
Plotter
AIS
DSB transceiver
Power cable 1.4 m
Antenna cable (FRU-CF-FF-XXM) (10/15/20 m)
* Option: CP03-37630 (30 m)
External Buzzer (OP03-21)
Junction Box (FI-5002)
NMEA Data Converter (IF-NMEA2K2)
:Option
Display Unit
RDP-157
MODEL 1815
Antenna Unit
RSB-127-120
RTR-120
Junction Box
(local supply)
Cable Assembly
(FRU-CF-F01)
Power supply
12 - 24 VDC
