5. OPERATION
5-41
5.30 Color Selections
5.30.1 Preset colors
This radar is preset with color combinations that provide best viewing in daytime,
nighttime and twilight. Below are the default color settings for each display item and
display color setting.
Display item, color design and color
1. Press the MENU key to open the menu.
2. Use the Cursorpad ( or ) to select [Brill/Color] and press the ENTER key.
3. Use the Cursorpad ( or ) to select [Display Color] and press the ENTER key.
Display Color options
4. Use the Cursorpad ( or ) to select the color design and press the ENTER key.
5. Press the MENU key to close the menu.
5.30.2 Custom colors
The custom color design lets you select preferred echo, background, characters,
range rings and marks colors. Select [Custom] in the [Display Color] menu item (see
section 1.34.1) to use the user selected echo, background, characters, range rings
and marks colors.
1. Press the MENU/ESC key to open the menu.
2. Use the Cursorpad ( or ) to select [Brill/Color] and press the ENTER key.
3. Use the Cursorpad ( or ) to select [Echo Color] and press the ENTER key.
Echo Color options
4. Use the Cursorpad ( or ) to select an echo color and press the ENTER key.
[Multi] displays echoes in colors of red, yellow and green according to descending
echo strength.
Display item Day Night Twilight Custom
Characters Black Red Green Green
Range rings, marks Green Red Green Green
Echo Yellow Green Green Yellow
Background White Black Blue Black
