10. MAINTENANCE, TROUBLESHOOTING
10-3
10.2 Fuse Replacement
The fuse on the power cable protects the equipment from overcurrent and equipment
fault. If the fuse blows, find the cause before you replace the fuse. Use the correct
fuse. A wrong fuse can damage the equipment.
10.3 Magnetron Life
When the life of the magnetron is reached, the targets do not appear on the display.
If long-range performance appears to have decreased, contact a FURUNO agent or
dealer about replacement of the magnetron. The magnetron changes with the type of
antenna unit.
Use the correct fuse.
A wrong fuse can damage the equipment and
cause fire.
Unit Type Code No. Remarks
Display unit (fitted
on power cable)
FRU-2P5S-FU-5A-B 000-168-869-10 12-24 VDC
Part Magnetron type Code No. Estimated life
Magnetron E3571 000-146-867-11 Approx. 2,000 hours
