SPECIFICATIONS OF MARINE RADAR
MODEL1815
1 ANTENNA UNIT
1.1 Antenna type Patch array
1.2 Radiator length 18-inch
1.3 Horizontal beam width 5.2°
1.4 Vertical beam width 25°
1.5 Sidelobe -20 dB or less (within ±20° of main-lobe)
-25 dB or less (outside ±20° of main-lobe)
1.6 Rotation 24 rpm
2 TRANSCEIVER MODULE (CONTAINED IN ANTENNA UNIT)
2.1 Tx frequency 9410±30 MHz
2.2 Radiation type P0N
2.3 Output power 4 kW
2.4 Duplexer Ferrite circulator
2.5 Intermediate frequency 60 MHz
2.6 Range scale, Pulse length (PL) and Pulse repetition rate (PRR)
Range (NM)
PL (s)
PRR (Hz approx.)
0.0625 to 1.5 0.08 360
1.5 to 2 0.3 360
3 to 36 0.8 360
2.7 Minimum range 25 m
2.8 Range resolution 25 m
2.9 Range accuracy 1 % of range in use or 0.01 NM, whichever is greater
2.10 Bearing resolution 5.2°
2.11 Bearing accuracy ±1°
3 DISPLAY UNIT
3.1 Screen type 8.4-inch color LCD, 640 (V) x 480 (H) dots, VGA
3.2 Effective radar diameter 128 mm
3.3 Brightness 0.27 to 600 cd/m
2
typical (16 steps)
3.4 Range scales and Ring interval
Range scale (NM) 0.0625 0.125 0.25 0.5 0.75 1 1.5 2 3 4 6 8 12 16 24 36
Ring interval (NM) 0.03125 0.0625 0.125 0.125 0.25 0.25 0.5 0.5 1 1 2 2 3 4 6 12
Number of rings 2 2 2 4 3 4 3 4 3 4 3 4 4 4 4 3
3.5 Marks Heading line, Bearing scale, Range ring, Tuning indicator, Cursor,
North mark, Variable range marker (VRM), Electric bearing line
(EBL), Target alarm zone, Zoom window, Waypoint mark*,
Origin mark*
3.6 Alphanumeric indication Range, Range ring interval, Display mode (H UP/ C UP/ N UP/ TM/
TRUE VIEW), Off-center (OFFCENT (M/A/C)), Heading data*,
Target trails, Tuning indicator, Target alarms, Echo stretch (ES),
