5. OPERATION
5-27
5.20.2 How to zoom
Relative or True zoom mode
1. Use the Cursorpad to put the cursor on the position desired.
2. Press the MENU/ESC key to open the menu.
3. Use the Cursorpad ( or ) to select [Display] and press the ENTER key.
4. Use the Cursorpad ( or ) to select [Zoom] and press the ENTER key.
Zoom options
5. Use the Cursorpad ( or ) to select [On] and press the ENTER key.
The ZOOM indication appears at the upper-left corner on the screen. The zoom
window and the zoom cursor also appear (see the illustration on the next page).
To quit the zoom, select [Off] instead of [On] and press the ENTER key.
6. Press the MENU/ESC key to close the menu.
Zoom window
Zoom cursor
Zoom indication
255.5
°
R
1.094
NM
VECT
TRUE
05:00
+
1.5NM
+
ZOOM(R)
To Next Page
