NMEA2000 Connector
(CAN bus connector)
CAN bus is a communication protocol that shares multiple data and signals through
a single backbone cable. You can simply connect any CAN bus devices onto the
backbone cable to expand your network onboard. With CAN bus, Ids are assigned to
all the devices in the network, and the status of each sensor in the network can be
detected. All the CAN bus devices can be incorporated into the NMEA2000 network.
For detailed information about CAN bus wiring, see “Furuno CAN bus Network
Design Guide”
(Type : TIE-00170)
on Tech-Net), or contact your dealer.
15.4.6
Extension Cable (Optional)
Step 1
Drill a round or square hole on the ship panel.
The diameter of the hole ranges from 23.5 mm to 25 mm.
Step 2
Thread the extended cable through the hole.
