4.8 Change the Specification Power for PR-240-CE
4-36
4.8 Change the S
pecification Power for PR-240-CE
When switching the power supply
, switch is ma
de below two spots. Factory shipm
ent is
220 V
AC specification.
1. Change of wiring
2. Change of jumper
Change the jumper
Change wiring
Change the red ca
ble with plug to
the
specification power
.
When changing the s
pecification (Factory
setting)
from 220 V
AC to 100 V
AC, move the secon
d
wiring to the first on the terminal board.
220VAC spec.
(default
）
1
2
3
4
100VAC spec.
1
2
3
4
Black
Black
White
White
SEL
1
15V
SEL
230V
Red
131
133
