Check List
i
How to call up option menus (MMSI registration etc,)
1. Make a jumper connection between #2 and #15 on [PRINTER] port. Or, jumper
connection between #25 and #26 of IF-8810.
2. [Menu] -> System -> [ENT] -> Password: xxxxxx
(Same as FM-8500, Ref to FQ-2005-015)
No. Items Remarks and Reference Pages Judge
1. Installation
1.1
Make sure VHF ANT and CH70 ANT connecters
are watertight.
1.2
Make sure of Grounding:
Transceiver unit, Junction Box and DMC IF
1.3
As for the connections of Junction Box, DMC IF
and a terminal board of Remote station, is the
wiring correct? Are they connected tightly?
1.4
Does the emergency light turn on the light and
control dimmer?
1.5
Is Transceiver unit supplied by the Reserve
Source?
1.6 Make sure of ALM output wiring.
See page 4-13.
In case of Normal Open (Close),
alarm output is always active
when receiving DIS/URG
messages. Conform with the
Drive circuits diagram.
2. Setup
2.1 Are Pos. and time data inputted automatically?
See page 4-18.
IEC61162-1: GGA > RMC >
GNS > GLL, ZDA
2.2 Have you registered MMSI correctly?
See page 4-3.
Menu->System->MMSI
Note: DSC communication is not
carried out without MMSI being
registered.
2.3 Have you registered Remote Handset ID number?
See page 4-6.
Turn on the power while pressing
Remote Handset [Menu] key.
To assign the same number is
prohibited.
2.4
Have you registered the Name of Transceiver unit
and Remote Handset?
(Remote Handset Name)
See page 4-7.
Register by [MENU] -> SYSTEM
->INTERCOM NAMING
2.5 Have you set up CH MODE?
See page 4-24.
The factory setting is INTL.
MENU->SYSTEM->CH MODE
2.6
Have you set up
OFFHOOK SPKR?
(ON/OFF set up of SP at the time when a
handset is OFF HOOK)
See page 4-20.
Menu->VOLUME->OFF HOOK
SPKR
Check List
To Next Page
