1.2 Operation
1-4
1.2.2 LCD display and Operation
The following item numbers in Table 1.2.1 are the number displayed on LCD in the
previous page. The same display is shown while operating Transceiver unit and Remote
Handset. [SHIFT] selection must be made in 3 seconds. After 3 seconds, “SHIFT”
indication on the LCD display disappears.
LCD dimmer adjustment: [SHIFT] -> [2]
LCD contrast adjustment: [SHIFT] -> [SHIFT], [LOG] or CHANNEL knob
As for the number of the item which "R" is added, the program is Russian Ver.
Table 1.2.1 Operation
Item Indication Operation key Outline
1
INTL, USA,
WX, CANADA,
INLND-WA,
PRIV, MEMO x
[SHIFT]->[7: INTL/USA]
Indicates an active mode
NOTE:
1. Indicated according to a setup
[MENU]->SYSTEM->CH MODE
2. “MEMO x” is indicated when a setup is made
[MENU]->MEMORY CHANNEL.
2
SP mark
(ON/OFF)
[SHIFT]->[1: SP mark]
ON/OFF setting for SP manually
NOTE:
[MENU]->VOLUME->OFFHOOK SPKR setting
3 Hi, Lo [SHIFT]->[0: HI/LO]
Hi: 25W, Lo: 1W
NOTE:
1. Indicated a mode channel allowed by
[MENU]->SYSTEM->CH MODE according to
the power setting in [MENU]->SYSTEM->CH
CONFIG
2. Output adjustment in [MENU]->SYSTEM->TX
POWER
*Even if SWR worse or PA heat protection is
activated, it continues current “Hi or Lo” indication.
4 Rx, Tx
PTT ON: Rx,
PTT OFF: Tx
Rx indication show when signal is being received.
Tx will be indicated if TX RF signal is detected.
5
ANT mark
(Display Bar: x3)
PTT ON: OFF,
PTT OFF: ON
Bar indicates SINAD which is Rx signal
0: No signals
1: Less than 20 dB SINAD
2: 20 to 40 dB SINAD
3: More than 40 dB SINAD
6
Envelope mark
(ON/OFF)
Indicated when there are unread messages in DSC
Rx message log.
NOTE:
[LOG]->RCVD ORDINARY, RCVD DISTRESS
7
SHIFT
(ON/OFF)
[SHIFT] Indicated when SHIFT function is available
8
CH
(Max. 3 digits)
In PRIV channel, indicates in a maximum of 3
digits.
Cont’d
To Next Page
