Furuno HS-8800 User Manual

5.2 I/O Port Specification
5-3
5.2.2 PRINTER Port(D-Sub 25P)
Table 5.2.2 PRINTER Port
IN/OUT Pin No. Signal Specification Remarks
1 STROBE N
2 D0
3 D1
4 D2
5 D3
6 D4
7 D5
8 D6
OUT
9 D7
10 ACK N
11 BUSY
12 PE
IN
13 SELECT
OUT 14 ALF N
IN 15 ERROR N
16 INT. N
OUT
17 SLCT IN N
18 F.GND
19 0 V
20 – 25 F. GND
Note;
In addition, use jumper connection of System protection unlock between #2 and #15
of [Printer] port
5.2.3 Handset MIC Connector
Table 5.2.3 MIC Connector
IN/OUT Pin No. Signal Specification Remarks
1 0 V
2 PTT SW N
3 MIC (H)
IN
4 MIC (C)
-46 dBm/600 ohm
OUT 5 HS SP (H) 2 mW/150 ohm
IN 6 HOOK SW N
OUT 7 +5 VDC
8 F. GND
