2.1 Main Unit
2-2
2.1.2 Interior
Photo 2.1.3 FM-8800S/D, Bottom Shield
Photo 2.1.4 FM-8800S, Top Shield
285 mm
CPU
DUP Rx
(FM-8800D)
CH 70 Rx
Tx/Rx
PWR
