3. MAINTENANCE, TROUBLESHOOTING
3-7
3.7 Parts Location and Parts List
Parts Location
RD-50
Rear cover opened
26P0006 board removed
RD-501/502
Cover opened
26P0006
26P0007
LCD
RD-501: 26P0012A
RD-502: 26P0012B
