Furuno RD-50 - Appendix 2 Screen Division

AP-2
APPENDIX 2 SCREEN DIVISION
The screen can be divided as shown below in the [Display] menu.
*: Can not select for the [DISP1] screen.
Screen division Display form Display item
Graphic Time, Speed, HDG/COG, HDG, ROT, Wind, Rudder, En-
gine, Shaft, Propeller Pitch
Digital Time, POSN, HDG/Speed 3 axis, Speed 3 axis, Speed 2
axis, Speed 1 axis, HDG, COG, WPT, Trip DIST, Total
DIST, Depth, ROT, Wind Speed, Wind Direction, Rudder
Angle, Rudder Angle Order, Water TEMP, Engine, Shaft,
Propeller Pitch
Graph Depth Graph, Water TEMP Graph
Digital
Time, POSN, Speed 1 axis, HDG, COG, WPT, Trip DIST,
Total DIST, Depth, ROT, Wind Speed, Wind Direction,
Rudder Angle, Rudder Angle Order, Water TEMP, Engine,
Shaft, Propeller Pitch
Digital
Time, POSN, Speed 1 axis, HDG, COG, WPT, Trip DIST,
Total DIST, Depth, ROT, Wind Speed, Wind Direction,
Rudder Angle, Rudder Angle Order, Water TEMP, Engine,
Shaft, Propeller Pitch
Graph Depth Graph, Water TEMP Graph
--
*
